Diamondback Model 450 Side Load Cart Tipper – High-Performance & Adjustable

Heavy-Duty Design. Maximum Efficiency. Built for Side Loaders.

The Diamondback Model 450 Side Load Cart Tipper, available at Cart Tipper USA, is engineered for high-capacity waste collection and dual-stream recycling applications. Designed with adjustable lifting arms, a patented shock-absorbing latching system, and a powerful 26K rotary actuator, this side-load tipper delivers maximum durability, efficiency, and flexibility.

With fewer moving parts for easier maintenance, the Model 450 ensures smooth lifting, minimal cart damage, and a high/deep dump for increased efficiency.

Diamondback Products logo featuring white lettering and geometric diamond shapes on a dark green background, representing Diamondback cart tippers and waste handling equipment.
Orange hydraulic cart tipper with black motor and steel lifting plate mounted on the rear of a white garbage truck for commercial waste collection.
Cart Tipper USA call-to-action graphic promoting cart lifters, cart tippers, replacement parts, and support services for commercial waste equipment.
Cart Tipper USA quote request graphic inviting customers to request pricing on cart tippers, cart lifters, and commercial waste handling equipment.

Why Choose the Diamondback Model 450 Side Load Cart Tipper?

✅ Eliminates Bottom Bar Cart Damage – Patented spring bottom bar latching system absorbs shock during the dump cycle, ensuring above-ground release and preventing damage to carts.

✅ High & Deep Dump – 50° dump angle allows for fast and efficient emptying, making it an ideal solution for side-load trucks handling dual-stream recycling programs.

✅ Heavy-Duty Lifting & Drive Arms –

  • 3/4” solid steel lifting and drive arms for superior durability.
  • The only side-load cart lifter with adjustable arms, making installation possible for most truck mounting heights.

✅ Self-Aligning Ball Bushings – Hardened steel, corrosion-resistant, and shockproof bushings require minimal lubrication, ensuring long-term performance.

✅ 26K Rotary Actuator – The largest actuator in the lifter industry, producing 26,000 ft/lb of torque at 3,000 psi. The shaft is designed with splined ends and a matching collar for enhanced durability over traditional keyways.

✅ Adjustable Mounting Heights –

  • Standard 42” to 55” mounting height (mounting plate included).
  • High-lift model (450-HL) available for mounting heights up to 81 inches.

Diamondback Model 450 – Dimensions, Key Features & Performance Specs

✔ Fits all ANSI Z245.30 (domestic two-bar style) carts & meets ANSI Z245.60 specifications
✔ Lifting capacity: 400 lbs @ 2000 psi
✔ Cycle time: 6-8 seconds at 3.2 gpm
✔ Dump angle: 50° for fast, high-efficiency dumping
✔ Adjustable mounting height: 42” to 55” (higher models available)
✔ Heat-treated pivot pins for long-lasting durability
✔ 3/8” thick faceplate for added strength
✔ Powder-coated finish for corrosion resistance
✔ Two-year limited warranty
✔ Made in the USA – Built for Performance & Longevity


Ground Clearance & Mounting Dimensions

Model 450 (Standard Side Load Version)

Mounting Height Clearance “A” Clearance “B” Clearance “C”
45” 14” 55.25” –
48” 14.5” 55.25” –
50” 14.5” 70” –

Model 450-HL (High-Lift Side Load Version)

Mounting Height Clearance “A” Clearance “B” Clearance “C”
51” 14.5” 72” –
54” 14.75” 74.25” –
56” 18” 81” –

📥 Download Diamondback Model 450 Brochure

📌 Order Now | Request a Quote

Why Waste Haulers Trust the Diamondback Model 450

✔ High & Deep Dumping Power – 50° dump angle for quick, high-throw emptying.
✔ Adjustable for Multiple Truck Heights – Works on 42” to 81” mounting heights.
✔ Prevents Cart Damage – Shock-absorbing latching system minimizes impact stress.
✔ Heavy-Duty & Low Maintenance – Self-aligning bushings & heat-treated components ensure long-lasting performance.
✔ Fast & Efficient Cycle Times – 6-8 seconds per lift at 3.2 gpm.
✔ Made in the USA – Manufactured, assembled, and tested for maximum durability.
