Why Choose the Diamondback 650 Rear Load Cart Tipper?
✅ Kicker Bar Friendly – Ultra-slim design increases clearance between the lifter and most standard kicker bars, making installation possible on more rear load trucks.
✅ High Hopper Sill Compatibility – Unique arm & faceplate design allows for mounting below the hopper sill edge, accommodating the increasing height of modern rear loaders.
✅ Eliminates Bottom Bar Cart Damage – Patented spring bottom bar latching system absorbs shock during the dump cycle, ensuring above-ground release and preventing cart damage.
✅ High & Deep Dump – Steep 45° dump angle provides high, deep throw into the hopper, increasing efficiency and speeding up cart emptying.
✅ Easy Cart Engagement – Sweeping action allows for smooth, effortless cart pickup, even on uneven terrain.
✅ Collapsible Top-Bar Holder – Top bar holder lays flat on the faceplate to prevent interference and damagewhen dumping flat-faced commercial containers.
✅ Maximized Ground Clearance – Rotates under the hopper, providing the highest possible ground clearancefor rear load trucks.
✅ Heavy-Duty Lifting & Drive Arms – ¾” solid steel lifting and drive arms for unmatched durability and strength.
✅ Low-Maintenance Self-Aligning Ball Bushings – Hardened steel, corrosion-resistant, and requires minimal lubrication for long-term performance.
✅ 26K Rotary Actuator – The largest actuator in the industry, producing 26,000 ft/lb of torque at 3,000 psi. Built with splined ends and a matching collar for increased lifespan and durability.
Diamondback 650 – Dimensions, Key Features & Performance Specs
✔ Fits all ANSI Z245.30 (domestic two-bar style) carts & meets ANSI Z245.60 specifications
✔ Lifting capacity: 400 lbs @ 1600 psi
✔ Cycle time: 6-8 seconds at 3.2 gpm
✔ Dump angle: 45° for optimal emptying
✔ Mounting height: 34” to 39” (includes mounting plate)
✔ Heat-treated pivot pins for extended lifespan
✔ 1/4” thick faceplate for extra durability
✔ Powder-coated finish for corrosion resistance
✔ Two-year limited warranty
✔ Key Clearance Dimensions:
- Overall height: 34.00”
- Faceplate thickness: 4.58”
- Arm width: 11.50”
- Lifting arm reach: 18.00”
- Mounting clearance: 20.50”
📌 Made in the USA – Built for Performance & Longevity
Why Waste Haulers Trust the Diamondback 650
✔ Designed for More Rear Load Trucks – Works with standard kicker bars & high hopper sills
✔ Minimizes Cart Damage & Reduces Downtime – Patented shock-absorbing system
✔ Heavy-Duty & Low Maintenance – Built with rugged steel components & self-aligning bushings
✔ Faster, More Efficient Dump Cycles – Steep dump angle & high throw capacity
✔ Easy Installation – Bolt-on mounting plate for simple, secure setup
